Fuel Tank 525 Lt
Fuel Tank 525 Lt: professional marine fuel tank by SIC Navy, 525 L, certified and made in Italy. Contact us for a quote.
Warranty Terms: Download The Warranty Policy Here
Download or View Documents
Tank Design & Selection
Description
The Fuel Tank 525 Lt (SKU HPSR0048) is a marine fuel tank that is manufactured by SIC Navy, holding 525 litres. It is engineered for large yachts and commercial vessels requiring extended range. It features a G1″1/ mm inlet, a 16/19 mm vent and 1 pick-up tube(s).
Exclusive innovation & versatility. All fittings rotate a full 360°, so the tank aligns perfectly with the hull’s geometry and inclination, extending hose life by reducing wear and kinking. The filling inlet is available in 38 mm and 50 mm; for optimal filling we recommend two vent valves on opposite sides (bow and stern), positioned diagonally. Additional pick-up tubes can be integrated to guarantee a constant fuel reserve and prevent engine starvation.
Compliant with Directive 2013/53/EU – reference standards ISO 10088 and ISO 21487. Rigid cross-linked polymer construction, supplied with fittings and an electronic level sensor. For custom configurations, DWG/STEP files or tailored molds, contact the SIC Navy technical team.
Additional information
| Lenght cm | 166 |
|---|---|
| Width cm | 63 |
| Height cm | 58 |
| Capacity (Litres) | 525 |
| Inlet Diameter (Carico) | G1"1/ |
| Tank Air Vent/Breather mm (Sfiato) | 16/19 |
| N° of Suction Pipes (N° di Pescanti) | 1 |
| Suction Pipe (Pescante) | 1" |
| Sku Code | HPSR0048, HPSR0049 |
